Compact 20kW to 40kW wall-mounted DC charger with 7" LCD touchscreen. IP55 protection, OCPP 1.6J protocol. Supports plug-and-charge, RFID card, and app-based start. Perfect for urban parking, dealerships, and workplace charging. European standard version available.
| Parameter | Model 1 | Model 2 | Model 3 |
|---|---|---|---|
| Model | CXE-D20KW | CXE-D30KW | CXE-D40KW |
| Output Power | 20kW | 30kW | 40kW |
| Current Range | 0-70A | 0-100A | 0-133A |
| Input Voltage | AC400V ±20% | ||
| Frequency | 50/60Hz | ||
| Output Voltage | 150-1000VDC | ||
| Constant Power Range | 300-1000VDC | ||
| Charging Gun | 5m (customizable length) | ||
| Network | 4G / Ethernet / WiFi | ||
| Communication Protocol | OCPP 1.6J | ||
| Current Accuracy | ≤1% | ||
| HMI | 7" color touchscreen | ||
| Peak Efficiency | 96% | ||
| Power Factor | ≥0.99 | ||
| Harmonic Current | ≤5% | ||
| Noise | ≤65dB | ||
| IP Grade | IP55 | ||
| Cooling | Fan cooling | ||
| Working Temp. | -30℃ ~ 50℃ | ||
| Altitude | ≤2000m | ||
| Dimensions (W×D×H) | 470×250×690mm |
7" LCD screen displays real-time charging data — time, voltage, current, power, and temperature at a glance.
Plug-and-charge, RFID card, password, and appointment charging. OCPP configurable for overseas markets.
IP55 protection — moisture-proof, waterproof, dust-proof, and flame retardant. Over/under voltage, overload, short circuit, leakage, and reverse connection protection.
Powerful data collection, transmission, and communication. Supports 4G, Ethernet, and WiFi. Optional CCS/GB/T/Tesla gun configurations.
Contact our sales team for pricing, customization options, or technical consultation. OEM/ODM services available.
